AMG750-1G-4GAT-1E4-P120 AMG750 Series Industrial Managed 4G Router, (5) 10/100/1000BT, (4) 30W PoE, WLAN, RS232/485

Brand: AMG Systems
ADI #:750-1G4GAT1E4-P120 Model #: AMG750-1G-4GAT-1E4-P120  Name: AMG750-1G-4GAT-1E4-P120 AMG750 Series Industrial Managed 4G Router, (5) 10/100/1000BT, (4) 30W PoE, WLAN, RS232/485
  • 2G/3G/4G/LTE CAT4 Cellular modem with Dual SIM card and fail-over support
  • Gigabit Ethernet WAN port supports load balancing or fail-over applications
  • 4 x Gigabit Ethernet ports with IEEE 802.3at PoE
Image of 750-1G4GAT1E4-P120

Product Overview

General Information

The AMG750 series Industrial Cellular Managed Router provides 5x Gigabit Ethernet ports. 1x Gigabit Ethernet port provides a configurable WAN connection while 4x Gigabit Ethernet ports provide connection for remote devices and optional IEEE 802.3at 30W PoE support. An integrated dual SIM 4G/LTE CAT4 modem provides connection in remote deployment scenarios where a wired connection is not available and combined with the wired WAN port can also act in fail-over or load-balancing modes. (Verizon, AT and T, PTCRB Certified) A dual band 2.4/5 GHz wireless connection is also provided for local wifi access and supports 802.11 a/b/g/n/ac as well as a USB port supporting device logging functions. An RS232 or RS485-Channel is provided to allow legacy serial data equipment to be connected at remote locations as well as a digital input and relay output for device monitoring and control applications. Dual power supply inputs are provided for the highest levels of system operation with a wide input range of 12-48VDC supported on non-PoE models. PoE models feature voltage-boosting technology ensuring that reliable PoE can be supplied to all 4 Ethernet ports when being powered by 24-56VDC sources. The USA models are fully Verizon, AT and T and PTCRB Certified. The EU models are fully e-Mark certified for use on Vehicles.

Main Features
  • 2G/3G/4G/LTE CAT4 Cellular modem with Dual SIM card and fail-over support
  • Gigabit Ethernet WAN port supports load balancing or fail-over applications
  • 4 x Gigabit Ethernet ports with IEEE 802.3at PoE
  • 2.4/5 GHz Dual band Wi-Fi radio 802.11 a/b/g/n/ac
  • Dual Power Inputs with 24-56VDC support including voltage booster technology
  • RS232/485 Serial data-channel for legacy equipment
  • USB Port supports remote data logging
  • Layer 3 support including static and dynamic routing RIP v1/v2, OSPF, BGP
  • VPN Tunneling supports IPsec, Open VPN, PPTP, L2TP and GRE with up to 16 independent tunnels
  • e-Mark certified for use on vehicles
Information
Category : Data Comm & Networking, Hubs, Routers & Switches, Network Routers, Products

Specifications

General Information

ADI Part Number
750-1G4GAT1E4-P120
Brand Name
AMG Systems
Manufacturer
AMG Systems
Manufacturer Part Number
AMG750-1G-4GAT-1E4-P120
Product Model
AMG750-1G-4GAT-1E4-P120
Product Name
Industrial 4G/LTE Cat4 EU PoE Router
Product Series
AMG750
Product Type
Router

Certifications

RoHS Compliant
Compliant

Warranty

Limited Warranty
Lifetime Warranty
