Elmdene G13802BM-C Switch Mode Power Supply Unit with Battery Monitoring, 12V DC 2A, H275xW330xD80mm
Brand: Elmdene by Potter
ADI #:G13802BM-C
Model #: G13802BM-C
Name: Elmdene G13802BM-C Switch Mode Power Supply Unit with Battery Monitoring, 12V DC 2A, H275xW330xD80mm
- Full Rated Current to Load + 0.5A battery charging
- Boxed and Unboxed Models with DIN Rail Mount Option 1 & 2A
- Universal Mains Voltage Input 90V - 264V ac
Product Overview
General Information
12V (13.8V dc ) 2A SMPSU with battery Monitoring - Metal Box 230Wx200Hx80D mm
Main Features
- Full Rated Current to Load + 0.5A battery charging
- Boxed and Unboxed Models with DIN Rail Mount Option 1 & 2A
- Universal Mains Voltage Input 90V - 264V ac
- Mains and Battery Monitoring
- Deep Discharge Protection
- Volt Free Fault Output - 1;Mains Fail
- Volt Free Fault Output - 2;Battery Failure,Output / Battery Fuse Failure,Output Short Circuit
- Mains Status LED Indication;Mains Status,Output Fuse Fail,Output Short Circuit,Battery Low or Missing
Information
Category : Access Control, Batteries & Power Supplies, Power Products, Power Supplies, Power Supplies & Boards, Products
Specifications
General Information
ADI Part Number
G13802BM-C
Amperage
2A
Brand Name
Elmdene by Potter
Manufacturer
Potter Electric Signal, LLC
Manufacturer Part Number
G13802BM-C
Product Line
G Range
Product Model
G13802BM-C
Product Name
G Range BM Power Supply
Product Series
BM
Product Type
Power Supply
Technical Information
Output Voltage
13.8V DC
Interfaces/Ports
Modular
Yes
Physical Characteristics
Depth
80 mm
Form Factor
Box Mount
Height
275 mm
Width
330 mm
Power Description
Input Voltage
120V AC, 230V AC
Output Current
2A
Warranty
Limited Warranty
Lifetime
Miscellaneous
Compatibility
Access Control CCTV
Environmental Certification
CE
Environmentally Friendly
Yes
